UL Recognized Quick Fit Terminals
Keystone offers UL recognized, male and female PCB quick-fit terminals and rivet mount male quick-fit terminals designed to hold up under repeated mating cycles.
An innovative Sturdi-Mount design provides increased PCB mounting strength and stability by maintaining the terminal's perpendicularity to PCB's during and permanently after wave soldering.
The rivet mount styles permit design and mounting flexibility for boards, panels and chassis mating environments. These quick fit terminals meet NEMA 2-1982-1988 and UL 310 specifications.
UL recognized quick-fit terminals are manufactured from brass and supplied with a tin plate. PCB mount versions are available in 0.110" (2.8mm), 0.187² (4.8mm), 0.205² (5.2mm) or 0.250² (6.4mm) tab sizes. Rivet mount versions are available in 0.110"(2.8mm), 0.187² (4.8mm), or 0.250² (6.4mm) tab sizes.
|
